| 产品型号 Product Type | JAXY D2207Z 10X42EDF | |||
  |
||||
| 放大倍率 Magnification | ★10× | |||
| 镜体材料 Body material | 塑钢PPS | |||
| 胶皮材料 Armor material | 橡胶(NBR+PVC) | |||
| 颜色 Color | ||||
| 物镜口径 Objective lens Ø | Φ42 | |||
| 目镜口径 Ocular lens Ø | Φ24 | |||
| 出瞳直径 Exit pupil Ø | Φ4.1mm ± 10% | |||
| 出瞳距离 Exit pupil distance (mm) | 18mm | |||
| 视场范围 Field of view (°) | ★7° | |||
| 视场范围 Field of view (at 1000M) | ★122m | |||
| 视场范围 Field of view (at 1000yds) | ★366ft | |||
| 视度系统 Diopter system | Right diopter ring | |||
| 瞳距可调范围 Interpupillary distance | 56～74mm | |||
| 调焦方式 Focus System | 中调Center Focus | |||
| 调焦透镜 Focusing lens | 目镜调焦Eye. | |||
| 视度可调范围 Diopter compensation | -4 To +4 Diopter | |||
| 调焦范围 Focusing Adjustment | -4 To +8 Diopter | |||
| 棱镜系统 Prism System | roof prism | |||
| 棱镜材料 Prism Glass Material | BaK4 | |||
| 光学组成 Optical Configuration | 物镜组成 Objective lens | 3E2G(即3片2组) | ||
| 目镜组成 Ocular lens | 4E3G(即4片3组) | |||
| 透镜类型 Lens Type | Spherical Lens(球面) | |||
| 光学材料 Optical Material | 全光学玻璃All optical glass | |||
| 透镜镀膜 Lens coating |
镀膜条件 Coating Condition | ★超级全多层宽带膜 Super Fully Multi Coating |
||
| 镀膜规格 Coating Spec. | ★400-700nm,R＜0.3%(AVG) | |||
| 棱镜镀膜 prism coating |
入射面镀膜 Coating Condition | 增透膜+镀铝 AR Coating +Aluminized |
||
| 镀膜规格 Coating Spec. | 420-680nm,R＜1.0%(ABS),蓝膜550nm（MGF2)。 | |||
| 防水，防雾Water/Fogproof | ▇ Yes □ No | |||
| 气体填充 Gas Filled | ▇ Nitrogen □ 其他 | |||
| 眼杯类型 Eye cup | 类型 Type | ▉Twist up □Fold down | ||
| 材质 Material | 橡胶(NBR) | |||
| 目镜盖 eye caps | 类型 Type | ▉ 连体式 □ 单体式 □ 其他 | ||
| 材质 Material | 橡胶(NBR+PVC) | |||
| 物镜盖 obj. Cover | 类型 Type | □连体式 ▉ 单体式 □ 其他 | ||
| 材质 Material | 橡胶(NBR+PVC) | |||
| 适合三脚架 Adapt to tripod | ▉ Yes □ No | |||
| 肩带 strap | ▉ Yes □ No | |||
| 软包 soft case | 类型 Type | □ 中性 ▉ 专有 □ 其他 | ||
| 材质 Material | 1200D牛津布包 | |||
| 肩带 strap | 类型 Type | □ 中性 ▉ 专有 □ 其他 | ||
| 材质 Material | 25mm宽织带 | |||
| 擦镜布 cleaning cloth | ▉ Yes □ No | |||
| 操作手册 instruction manual | ▉ Yes □ No | |||
| 包装 packaging | ▉ Yes □ No | |||
| 尺寸(长×宽×高) Size(Length×Width×Height) | 150×53×128mm | |||
| 重量 Weight approx | 约640g 650g |
|||
